Castle Creations CC BEC Pro 20A 12S 50,4V Voltage Regulator

Overview

The Castle Creations CC BEC Pro (CC010-0004-01) is a powerful external BEC voltage regulator that reduces the drive battery voltage to a suitable voltage for the receiver and servos. With a maximum input voltage of 50.4V (12S LiPo) and a peak output of 20A, this BEC is designed for applications with multiple high-power digital servos, including 1/5 RC cars, large aircraft, 500+ class helicopters, and UAS systems. The output voltage is adjustable from 4.9 to 12.5V via Castle Link.

Features

• 20A maximum peak output
• Suitable for up to 12S LiPo / 50.4V
• External BEC for systems without a suitable internal BEC
• Output voltage adjustable from 4.9 to 12.5V
• Factory setting: 5.1V
• Programmable via Castle Link
• Designed for multiple high-power digital servos
• Suitable for 1/5-scale RC cars
• Suitable for large aircraft and 500+ class helicopters
• Also suitable for UAS applications
• Two output cables for better power distribution to the receiver
• Compact housing
• Silicone conformal coating provides some water resistance, but the BEC is not waterproof
• Maximum current ratings depend on the input voltage
• Designed for use with high servo loads
